FEATURES
◇ Easy and correct readout.
◇ High measuring accuracy.
◇ Measurements are possible even under a strong magnetic field.
◇ LSI-circuit provides high reliability and durability.
◇ Input overload protection is provided.
◇ LCD display for low power consumption and clear readout even in bright ambient light conditions.
◇ In-line pushbuttons allow one hand operation.
◇ Light-weight and compact construction for easy operation.
◇ Low battery condition is indicated on the LCD display.
SPECIFICATIONS
GENERAL SPECIFICATIONS
Display :LCD (Liquid Crystal Display) Max. display 1999.
Range :9 range, whole range value (from 0.1pF to 20mF)
Overload protection : Display “1”.
Calibrate Adjustment :Have two internal adjustment. One is panel Zero adjustment.
Zero Adjustment :Manual (range:±20pF)
Over-range dispaly :Display“1”.
Sampling Time :0~5second
Operating Temp :0℃ to 40℃.
Operating Humidity :80% MAX.R.H.
Battery :9V (6F22 or the equivalent
Battery Life : alkaline battery: approx.200 hours.
Zinc-Carbon battery approx. 100 hours
Typical consumption current: 3~4mA (RANGE: 200pF-200uF)
Standard Accessories: Test alligator clips (red & black)…1 pair.
Instruction manual………………..1 pc.
